CORNERED Speaker, 5¼"+5¼"+1"

60Wrms @ 8Ohm / 30W @ 100V

IP65, EN54, white

Art. Nr:
CI5V-WH

UVPCHF415.00
Beschreibung


Ci5 & Ci5V • INSTALL LOUDSPEAKER WITH 90° SHAPE HOUSING, IP64 & EN54 RATING


Ci5 is a very versatile and compact 2-way full-range speaker with strong output and solid bass performance. With a wide and uniform dispersion, full coverage can be achieved by installing relatively few speakers, which makes the Ci5 especially suited for in-door and outdoor commercial installations. The patented triangular Cornered design and our new sliders ensures fast and easy installation, flush in corners or onto walls and ceilings without brackets. Cabinets can be coupled together to increase coverage to 180, 270 or 360 degree.
The cable terminal is hidden making the cable connection invisible both in vertical and horizontal applications. The tweeter features a switchable protection circuit for added safety and the Ci5-V model can be run in either 8 ohm or 70/100 volt. In high-impedance mode, tap settings for 3,5 - 7,5 - 15 or 30 watt output is conveniently located on the front baffle.
Ci5 is the perfect elegant speaker solution for commercial installations in entertainment venues, shopping malls, hotels and meeting rooms.




TECHNICAL DATAS:


Power handling, IEC268: 80 watt
Power handling, peak: 320 watt
Sensitivity, 2,83V/1m: 88 dB
Maximum SPL, long term: 107 dB
Maximum SPL, peak: 113 dB
Frequency response: 55-20.000 Hz
Nominal impedance: 8 ohm
Power Selector 100V (Ci5V): 30 / 15 / 7.5 / 3.5 watt
Dispersion: 100x100 degrees
Measurements (HxWxD): 450x209x150mm
Weight: 3.6 kg
