2-way Passive Point Source

The ARTEC-308-T 2-way passive full range loudspeaker utilizes a 8" low frequency transducer and the M-26 compression driver. The cabinet is manufactured using top quality Birch plywood and finished with a durable black paint finish. The 8" woofer provides an exceptional bass response considering the cabinets reduced size.
The Artec-300 cabinets are constructed from Baltic Birch plywood and finished with a durable ISO-flex paint. The trapezoidal enclosure design helps eliminate standing wave coloration and at the same time, permits close-packed horizontal or vertical arrays.
A rotatable horn allows the systems to be installed in either the vertical or horizontal position maintaining the needed dispersion characteristics. The cabinet is delivered with a U-bracket mount and factory installed line transformer.


HAUPTMERKMALE:

1 x 8GU low frequency loudspeaker
1 x M-26 compression driver
Rotatable 90º x 60º hornVertical or horizontal positioning
VESA75/VESA100 standard threaded mounting points
Version with factory installed multi-tap transformer
12.5 W/25 W/500 W/100 W (70 V)25 W/50 W/100 W (100 V)
AXU-A308 U-Bracket included

Datenblatt
