Die Kompaktzentrale PA6120 verfügt über 6 Zonen und einen internen CPU für die Selektion von Gong-und Vorrangfunktionen.
Über rückseitige DIP-Switches können foglende Funktionen konfiguriert werden:
• priority management
• muting of inputs
• warning signal and enabling of the VOX function
• zone call
• VOX release time

Die Zentrale PA6120 verfügt zudem über ein Medienmodul mit CD Player, Tuner und USB/SD-Card Schnittstelle.

Functional features

6-off outputs.
2-off XLR balanced/unbalanced microphone inputs, with Phantom supply.
1-off microphone input (XLR) / PMB Series microphone station (RJ45).
2-off MIC./LINE inputs with operating mode selection.
2-off auxiliary inputs for external sound sources (TAPE/CD).
Emergency input from PABX.
Socket for connection of PMB106/PMB106-G microphone stations (RJ45 connector, CAT5 SFTP cable).
Balanced line output for connection with other amplifiers.
Loudspeakers output terminal strip (50-70-100V / 8ohm).
Terminal strip for external DC power supply.
Precedence and override terminal strip.
“MUSIC ON HOLD” terminal strip.
Activation threshold/level control of the warning signal (Chime).
Music signal level adjustment (zone 1 to 6).
Possibility to connect an external amplifier.
Output for recorder.
Selectable mains voltage (230/115V).

Parameters of Product:
Rated output power 120 W
Constant voltage outputs 100 - 70 - 50 V
Low impedance outputs 8 ohm
Distortion (@ rated power) <1%
Tones control Treble/Bass ±10 dB
Microphone inputs 2, balanced, XLR with fixed Phantom / MIC.1 with A.P.T. adjustment
Microphone inputs / Desk microphones 1, balances, XLR with fixed Phantom / 1 RJ45
Microphone inputs / line 2, balanced, XLR - PHANTOM / MIC / LINE selector
Auxiliary inputs 2, RCA (1 CD + 1 TAPE)
Emergency/Tel input 1, balanced, termin strip (HOT-COM-GND) with audio level and A.P.T. adjustment
Sound sources CD - USB - SD/MMC Card - TUNER
Signal outputs 5
Power supply Mains: 230/115 Vac - 50/60 Hz • External: 24 Vdc
Consumption @Pmax active power: 280 W / apparent power: 325 VA
Mounting rack mounting with AC50/3 optional brackets
Dimensions 432 x 133 x 360 mm (3U)
Weight 14 kg
