Neue, kompakte Desktop-Mixer für unzählige Einsatzzwecke. Die Mi-Serie ist die perfekte Lösung überall dort, wo auf kleinem Raum Grosses erwartet wird! Mi-10 und 12 haben sogar einen eingebauten Digital-Effekt welcher die Funktionalität diser kleinen "Kraftzwerge" optimal ergänzt.


TECHNISCHE DATEN:

System type: Compact 10-channel 2-bus mixer
Input Connectors:
Mic Input: Balanced XLR-F
Line Input: Balanced JACK
Input Sensitivity:
MONO INPUT CHANNEL - Mic Input: from -10 to -50 dB
MONO INPUT CHANNEL - Line Input: from +20 to -40 dB
STEREO INPUT CHANNEL - Line Input: +4 / -10 dB
Input Impedance:
MONO INPUT CHANNEL - Mic Input: 2 Kohm
MONO INPUT CHANNEL - Line Input:10 Kohm
STEREO INPUT CHANNEL - Line Input: 10 Kohm
Output Connectors: Unbalanced JACK
Output Levels: Maximum level all outputs: +22 dBu
Headphones output impedance: 32 ohm
Mono Input channel equalization:
HIGH (shelving): ±15 dB @ 12KHz
MID (peaking): ±15 dB @ 2.5KHz
LOW (shelving): ±15 dB @ 80Hz
Effects: 256 (16 presets x 16 variations): HALL, ROOM, VOCAL and PLATE reverbs STEREO and MONO TAP DELAY REV + DELAY, REV + TAP DELAY, REV + CHORUS
Crosstalk (meas. at 1 KHz): > 82 dBu
HUM & Noise unweighted: < -93 dBu
THD + Noise at +4dB, 1kHz: < 0,008 %
Power Supply: 18 VAC 500 mA (use only supplied AC/AC ADAPTER)
Power consumption: 32 W
Weight:1.5 lb
Dimensions (W x H x D): 200x266x60 mm
