160W, 70/100V, 4O professional mixer amplifier.

This new series of audio power amplifiers was designed to fulfil an evolving market in the most flexible and professional manner.

The new range responds to precise operating criteria and was designed and tested to guarantee total reliability of use, also with continuous operation.

Thanks to the use of power supply switching with SMPS (switch mode power supply) technology and to the constant voltage output 70/100V obtained electronically without transformers, it was possible to design the amplifier in only one rack unit, succeeding in containing the weight and size.



Hauptmerkmale:

· Speakers overload and short-circuit protection circuit
· Led start-up indicator
· Led level indicator
· Volume general control (Master)
· Separated Level Controls for 1÷5 inputs
· Low and high tone adjustment
· Illuminated knobs
· 4 MIC / MIC Phantom 48V / LINE inputs balanced on Euroblock terminal
· 3 AUX switchable inputs from front selectors
· 1÷4 Inputs with independent priority function (VOX / Contact) on other inputs selectable by dip-switch 1÷4
· Function MAIN - IN/OUT
· 3 outputs, one at constant impedance (4O) and two at constant voltage (70/100V)
· CHIME function independent for each input (routing)
· REC OUT output on RCA
· Line level output balanced on Euroblock terminal
· 230/117V~ 50/60Hz autoswitch power supply
· 1U 19" rack adapters
